Montech Century Gold 850W Full Modular, Full Japanese Capacitors Power Supply (5 YEARS WARRANTY BY TECH DYNAMIC PTE LTD)

Product Name

CENTURY 850

ATX Version

ATX12V

PFC

Active PFC (>0.9 typical)

Input Voltage

100-240Vac

Input Current

12A

Input Frequency

47-63Hz

Dimensions (L*B*H)

140*150*86mm

Fan Size

120mm ( FDB Fan )

Hold Up Time

10msec (minimum) at 80% of full load at 230Vac input.

Efficiency

90% Typically

MTBF

>100,000 Hours

Operating Temperature

0-45°C

Protections

OCP/OVP/UVP/OPP/SCP/OTP

Regulatory

cTUVus / TUV / CB / CE / RoHS / FCC

Connectors

M/B 20+4Pin

1

CPU 4+4Pin

2

PCIE 6+2

6

SATA

10

Molex 4Pin

3

FDD

1

AC Input

100-240Vac 47-63Hz 12.0A

DC Output

+3.3V

+5V

12V

-12V

+5VSB

Max. Output Current

20A

20A

70.5A

0.3A

2.5A

Max. Output Power

110W

846W

3.6W

12.5W

Total POWER

850W
