SSUPD Meshroom D Mini ITX Black/White case support up to MATX motherboard (1 YEAR WARRANTY BY CORBELL TECHNOLOGY PTE LTD)
- Low stock - 2 items left
- Inventory on the way
Specifications
Expansion slots
3 slots
4.6 slots with expansion bracket
Front interface
Variant A: 1x USB 3.2 Gen 1 Type-C (10 Gbps), 2x USB 3.0 Type-A (5 Gbps)
Variant B: 1x USB 3.2 Gen 2 Type-C (20 Gbps), 1x USB 3.0 Type-A (5 Gbps), 1x Power button
Rear interface
Variant A: Power button
Variant B: N/A
Top and front panel
Fine mesh panels
Side panel
Fine mesh panels
Tool-less push-to-lock
Both side, top, and front panels
2.5" drive mounts
With SFX PSU: 5 × 2.5” SSD
With ATX PSU: 4 × 2.5” SSD
3.5" drive mounts
With SFX PSU: 3 × 3.5” HDD;
With ATX PSU: 2 × 3.5” HDD
Side fan mounts
Left side: 2x 120 / 140 mm (PSU right or top mounted)
Right side: 1x 80 / 92 mm
Front fan mounts
1x 120 / 140 mm (SFX PSU top mounted)
Rear fan mounts
1x 80 / 90 mm
Dust filters
Bottom
Compatibility
Motherboard compatibility
Mini ITX / Mini DTX / Micro-ATX (requires optional expansion bracket)
Power supply type
ATX / SFX-L / SFX
Power supply max length
150 mm (PSU mounted on left side);
140 mm (PSU mounted on right side);
130 mm (PSU mounted on top)
CPU cooler height
Max 142 mm tall with no side fan bracket installed
Max 138 mm tall with side fan bracket installed
GPU max length (ITX MB)
3-slot mode: 325 mm length x 140 mm height;
3.4-slot mode: 325 mm length x 136 mm height
GPU max length (MATX MB)
3-slot mode: 325 mm length x 140 mm height with expansion bracket;
4.6-slot mode: 325 mm length x 136 mm height with expansion bracket
Side water cooler
ITX MB: max 323 mm length x 144 mm width x 65 mm thick (radiator+fans);
MATX MB: max 279 mm length x 124 mm width x 65 mm thick (radiator+fans)
Bottom water cooler
ITX MB: max 326 mm length x 144 mm width x 45 mm thick (radiator+fans) allows 22 mm width GPU;
MATX MB: max 326 mm length x 124 mm width x 55 mm thick (radiator+fans) allows 37 mm width GPU
General
Case dimensions
Variant A: 363 x 167 x 254 mm / 14.29 x 6.57 x 10.01 inch
Variant B: 363 x 167 x 259 mm / 14.29 x 6.57 x 10.19 inch
Without feet: 363 x 167 x 247 mm / 14.29 x 6.57 x 9.72 inch
Package dimensions
435 x 195 x 315 mm / 17.13 x 7.68 x 12.4 inch
Net weight
Variant A: 2.85 kg / 6.3 lb
Variant B: 2.9 kg / 6.4 lb
Gross weight
Variant A: 3.4 kg / 7.5 lb
Variant B: 3.5 kg / 7.7 lb
Volume
Variant A: 15.4 liters / 14.96 liters without feet
Variant B: 15.7 liters / 14.96 liters without feet
Case material
SGCC powder coated steel, plastic, PVC filter
Package contents
Case, accessory box, user manual
Warranty
2 years
